BW1280

IP65 moving pixel-mappable beam & wash

BW1280 is an exceptionally powerful IP65 moving pixel-mappable beam & wash,high lumen delivery ouput and ready for all weathers.

● 900W

● Pixel mapping & beam & wash

● 8,980lm

● IP65 Rating

SPECIFICATIONS

LIGHT SOURCE

● Light Source: 12x 80W RGBW

● Light Aux Source: 168x 1W 1800K + 168x 1W 6500K (optional)

● 8,980lm

● CRI: Ra≥72

● CTO: 2700K-6500K

● Life expectancy: 50000hours

OPTICS

● Beam angle: 2.8°-31°

● Field angle: 5°-46°

● Lux(Spot): 40,000Lux @ 5m

● Lux(Flood): 1,300Lux @ 5m

● Selectable PWM: 600Hz, 1200Hz, 2000Hz, 4000Hz，6000Hz, 25000Hz

DYNAMIC EFFECTS

● Tilt: 200°

● Tilt Ranges: 60°, 180°, 200°(endcode)

● Dim Modes: 6

● Dim Curves: 4 selectable dimming modes available

CONTROL

● Protocols: DMX512, RDM, optional(Art-Net, sACN)

● Optional WDMX+CRMX(Timo FX RDM)

● Display: LCD

● Channels: 20/53/101/155/179/47/169A/169B CHs

ELECTRONICS

● Dimmer: linear 0 ~ 100% electronic 16bit dimmer

● Strobe Rate: 0 to 25Hz

● Operating temperature: -20° ~ +45°

ELECTRICAL

● Mains power supply: 90-240VAC- 50/60Hz

● Max power consumption: 900W

PHYSICAL

● Housing Material: Magnesium alloy, black

● Cooling: Temp controlled, noiseless fan for forced air

● Signal connection: Seetronic XLR 5p IN/OUT

● Power connection: Seetronic powerCON TRUE1 In/Out

● IP65 RJ45 Ethernet In/Out(optional)

● USB-C: for upgrading firmware

● Dimensions (LxWxH): 1000x332x219mm

● Weight: 30.2kgs

● IP rating: IP65

CERTIFICATIONS

● Certifcations: CE,RoHS

Standard Included

● 1x BW1280

● 1x 2.0m Seetronic Powerkon IP65 power cord

● 2x Omega clamps

● 1x Manual

● 2x Safety Cable

Optional Accessories

● Flight case 1-in1

● IP Rated EtherCon Cable

● IP DMX Cable

DIMENSION

Filename	size	Uploaded	Download
Datasheet
BW1280 datasheet.pdf	150k	2025-11-13
