GALAXY FLASH IP G7
IP65 moving strobe & wash
G7 is an exceptionally powerful IP65 moving strobe & wash,high lumen delivery ouput and ready for all weathers.
● 1500W
● Strobe, wash
● 91,600Lm
● IP65 Rating
| SPECIFICATIONS |
|
LIGHT SOURCE ● LEDs: 672 x 1.5W tri-RGB LEDs, 288 x 2W CW, 144 x5W CW ● 91,600lm ● CRI: Ra≥90 ● CTO: 2700K-8000K ● Life expectancy: 50000 hours OPTICS ● Beam Angle: 117° ● Selectable PWM: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 25000Hz DYNAMIC EFFECTS ● Tilt180° ● Tilt Ranges: 0°to180°(endcode) ● Standalone Color Mixing: Yes ● Dim Modes: 4 selectable dimming modes available ● Built-in Automated Programs:Yes CONTROL ● Protocols: DMX512, RDM, optional (Art-Net, sACN) ● Optional WDMX+CRMX(Timo FX RDM) ● Display: LCD ● Channels: 8/11/13/24/30/61/82/102/125 CHs |
ELECTRONICS ● Dimmer: linear 0 ~ 100% electronic 16bit dimmer ● Strobe Rate: 0 to 30Hz ● Operating temperature: -20° ~ +45° ELECTRICAL ● Mains power supply: 100-240VAC- 50/60Hz ● Max power consumption: 1500W PHYSICAL ● Housing Material: Magnesium alloy, black ● Cooling: Temp controlled, noiseless fan for forced air ● Signal connection: Seetronic XLR 3/5p IN/OUT ● Power connection: Seetronic powerCON TRUE1 In/Out ● IP65 RJ45 Ethernet In/Out(optional) ● Dimensions (LxWxH): 424x187.96x357.5mm ● Weight: 10.3kgs ● IP rating: IP65 CERTIFICATIONS ● Certifcations: CE,RoHS Standard Included ● 1x G7 ● 1x 2.0m Seetronic Powerkon IP65 power cord ● 1x integrated fold clamp of S7/C7/G7 series ● 1x Manual ● 1x Safety Cable Optional Accessories ● Flight case 1-in-1 ● IP Rated EtherCon Cable ● IP DMX Cable |
| DIMENSION |
| Filesname | Size | Uploaded | Download |
| MANUALS | |||
 G7 User Manual.pdf |
800k | 2025-07-01 |  |
