STRIKE M PRO IP S7
IP65 moving strobe
S7 is an exceptionally powerful IP65moving strobe,highlumen delivery ouput and ready for all weathers.
● 1500W
● Pixel mapping
● 92,500lm
● IP65 Rating
| SPECIFICATIONS |
|
LIGHT SOURCE ● Strobe Panel LEDs: 784x 1.5W RGB LEDs(tri-color) ● LED Segments: 14(2x7) ● Strobe Tube LEDs: 392x 2W CW LEDs ● LED Segments: 28(2x14) ● 92,500lm ● CRI: Ra≥90 ● CTO: 2700K-8000K ● Life expectancy: 50000hours OPTICS ● Beamble: 117° ● Selectable PWM: 600Hz, 1200Hz, 2000Hz, 4000Hz，6000Hz, 25000Hz DYNAMIC EFFECTS ● Tilt180° ● Tilt Ranges: 0°to180°(endcode) ● Standalone Color Mixing: Yes ● Dim Modes: 4 selectable dimming modes available ● Built-in Automated Programs: Yes CONTROL ● Protocols: DMX512, RDM, optional(Art-Net, sACN) ● Optional WDMX+CRMX(Timo FX RDM) ● Display: LCD ● Channels: 8/11/13/24/30/47/68/74/97 CHs |
ELECTRONICS ● Dimmer: linear 0 ~ 100% electronic 16bit dimmer ● Strobe Rate: 0 to 30Hz ● Operating temperature: -20° ~ +45° ELECTRICAL ● Mains power supply: 100-240VAC- 50/60Hz ● Max power consumption: 1500W PHYSICAL ● HousingMaterial: Magnesium alloy,black ● Cooling: Temp controlled, noiseless fan for forced air ● Signal connection: Seetronic XLR 3/5p IN/OUT connectors ● Power connection: Seetronic powerCON TRUE1 In/Out ● IP65 RJ45 Ethernet In/Out(optinal) ● Dimensions (LxWxH): 424x187.96x357.5mm ● Weight: 12.7kgs ● IP rating: IP65 CERTIFICATIONS ● Certifcations: CE,RoHS Standard Included ● 1x S7 ● 1x 2.0m Seetronic Powerkon IP65 power cord ● 1x integrated fold clamp of S7/C7/G7 series ● 1x Manual ● 1x Safety Cable Optional Accessories ● Flight case 1-in1 ● IP Rated EtherCon Cable ● IP DMX Cable |
| DIMENSION |
| Filename | size | Uploaded | Download |
| MANUALS | |||
 S7 User Manual.pdf |
150k | 2025-07-01 |  |
